CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix E MN/CDM570L.IOM
E–37
Parameter File Tag Values Associated with Parameter
ETHER_IP_SNET IP Address in the format 192.168.1.50/24
HDLC_ADDR_MODE
Small Network Mode
Large Network Mode
Point-To-Point Mode
QOSC
If there are no QoS rules configured, (or) system is not in Max-Pri (or) Min-Max mode, then param file will not have an entry for
QoSC. Otherwise, the rules will be in the following format.
QOSC### = SrcIP/Mask DstIP/Mask PROT spm spM dpm dpM mxB mb P W F
QOSC#1 = ***/* ***/* RTP *** *** *** *** 22222 0 4 N Y
QOSC#2 = 11.12.13.14/32 22.22.33.44/32 UDP 11111 22222 33333 44444 99999 0 0 Y N
Where
spm – source port min; spM – source port Max; dpm – Destination port min; dpM – Destination port Max
mxB – Max bandwidth in kbps; mb – minimum bandwidth in kbps [Total aggregate min bandwidth of all the QoS rules should be
less than the Tx-Data rate of the system.]
P – Priority; W – WRED; F – Filter; [Y – Yes, N – No]
QOSCDEFR
The default rule always exists in the system and in param file, but not meaningful if QoS mode is DiffServ. The format is
QOSC### = SrcIP/Mask DstIP/Mask PROT spm spM dpm dpM mxB mb P W F
QOSCDEFR#0 = ***/* ***/* ALL *** *** *** *** 99999 0 9 N N
DIFFSSV#0 … DIFFSSV#11
The DiffServ rules are meaningful only when QoS mode is DiffServ. Otherwise, these parameters can be discarded. The format is
as follows. The first column is
DIFFSSV#0 = 0 99999
NOTE: Donor use this from PARAM file, instead use DTG? Command.
IGMP_QRYP
A decimal value of
1…600
