CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix F MN/CDM570L.IOM
F–7
Step Task
7 CDM-IP 1 Route Table should display the following:
Route Name Dest IP/SNet Bits Next Hop MultiCast State
Route001...[test 172.16.10.0/24 POINT-TO-POINT N/A toSat]
Next, perform the following steps on CDM-IP 2:
Step Task
8 From Transmitter Configuration Main Menu submenu select Route Table [R] submenu.
9 Enter 1 to configure the first route.
10 Enter a suitable name
11 Set IP Address to 172.17.10.0
12 Set Number of Subnet Bits to 24
13 For Interface to which route is destined to <E-Ethernet S-Satellite Enter : S> select S
14 CDM-IP 2 Route Table should display the following:
Route Name Dest IP/SNet Bits Next Hop MultiCast State
Route001...[test 172.17.10.0/24 POINT-TO-POINT N/A toSat]
At this point the basic configuration is over and you should be able to:
• Ping PC 1 from PC 2 and vice versa
• Ping CDM-IP 2 from PC 1 and vice versa
• Pass any other data between the 2 PCs
Step Task
15 From PC1:
Ping 172.17.10.1 (CDM-IP 1)
Ping 172.16.10.1 (CDM-IP 2)
Ping 172.16.10.11 (PC 2)
16 From PC2:
Ping 172.16.10.1 (CDM-IP 2)
Ping 172.17.10.1 (CDM-IP 1)
Ping 172.17.10.11 (PC 1)
