CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix K MN/CDM570L.IOM
K–21
(ODU: Enable) INFO: Assembly+SN
ASSEMBLY INFO: M&C
AS:11565-4 SN:001370891
The blinking cursor is on the M&C. Use the ▲ ▼ arrow keys to view
additional assembly and S/N information for the Up Converter, Down
Converter, and HPA.
(ODU: Enable) INFO: FW (Firmware)
FIRMWARE INFO: M&C
FW:10303-1D VER:01.01.05
The blinking cursor is on the M&C. Use the ▲ ▼ arrow keys to view
additional assembly and S/N information for the Up Converter, Down
Converter, and HPA.
K.3.3.1.2.1.3 (ODU: Enable) Status
STATUS:PS:OK RF:OK UC:OK
LNA:OK AG:OK HP:OK DC:OK
Use the ◄ ► arrow keys to select a feature, and then press ENTER to view more detailed status
information. The nested screens provide continually-updated, read-only operational summary
information, as follows:
Feature
(Selection)
Designates Detailed Status Display Example
PS Power Supplies
P/Supplies: 7V:OK 17V:OK
-7V:OK 12V:OK
RF Reference
REF:WARM 72M:OK RANGE:NA
SRC:INT XLK:NA PHASE:NA
UC Up Converter
UPCONV STATUS: OVRTMP:OK
SSYN:OK KSYN:OK PRG:OK
LNA
Low Noise
Amplifier
A detailed status display screen is not available for this
selection.
AG AGC Status
AGC STATUS: EIP:OK
LOOP:OK IIP:OK
HP HPA Status
HPA: OVERTMP:OK 9.75V:OK
-5V:OK BIAS:OK PRG:OK
DC Down Converter
DNCONV STATUS: OVRTMP:OK
LSYN:OK KSYN:OK PRG:OK
