CDM-570/570L Satellite Modem with Optional IP Module Revision 12
Appendix L MN/CDM570L.IOM
L–5
L.3.3.1 (SELECT:) Config (Configuration)
CONFIG: Rem All Tx Rx CEx
Frame Intfc Ref Mask ODU
For ODU operations, use the ◄ ► arrow keys to select Mask or ODU, and then press ENTER.
L.3.3.1.1 CONFIG: Mask
Alarm Mask: Transmit
Receive Ref BUC LNB (◄►)
For ODU operations, use the ◄ ► arrow keys to select BUC or LNB, and then press ENTER.
L.3.3.1.1.1 (CONFIG: Mask) Alarm Mask: BUC
BUC Alarm:
Active Masked (◄ ►,ENT)
Use the ◄ ► arrow keys to select Active or Masked, and then press ENTER. By selecting
Masked, no alarm will be generated.
L.3.3.1.1.2 (CONFIG: Mask) Alarm Mask: LNB
LNB Alarm:
Active Masked (◄ ►,ENT)
Use the ◄ ► arrow keys to select Active or Masked, and then press ENTER. By selecting
Masked, no alarm will be generated.
L.3.3.1.2 CONFIG: ODU (Outdoor Unit)
ODU (Outdoor Unit):
BUC LNB (◄ ►,ENTER)
Use the ◄ ► arrow keys to choose between controlling and monitoring a BUC (Block Up
Converter) or an LNB (Low-Noise Block Down Converter). Press ENTER when done
L.3.3.1.2.1 (CONFIG: ODU (Outdoor Unit)) BUC
BUC: M&C-FSK DC-Power
10MHz Alarm LO Mix (◄ ►)
Use the ◄ ► arrow keys to select M&C-FSK, DC-Power, 10MHz, Alarm, LO, or Mix, and
then press ENTER.
