L.4 ODU Operations via the CDM-570L Base Modem HTTP Interface
L.4.1 ODU-Accessible Base Modem HTTP Interface – Overview
The CDM-570L Satellite Modem’s embedded HTTP Interface provides an easy to
use application to configure and monitor all aspects of a BUC or LNB. For a
complete overview of the features for this interface, see Chapter 7. BASE
MODEM HTTP INTERFACE.
L.4.1.1 Base Modem HTTP Interface – Home Page and Menu Tree
Once a web browser is opened
and a valid IP address has been
entered, the CDM-570L Satellite
Base Modem HTTP Interface
“splash” page is displayed:
The options available through the CDM-570L Base Modem HTTP Interface are illustrated via the
following menu tree – operations not specific to the ODU appear dimmed and are explicitly defined
in Chapter 7. BASE MODEM HTTP INTERFACE:
Home Admin
Config Mdm
Stats Maint
Home Access Modem Modem Status Unit Info
Contact Remote Modem Utilities Modem Logs
Support AUPC
BUC
LNB
