ESAB Cutting Systems
CROSSBOW Page 111
AUTO RETURN TO
START
Automatically move torch at rapid speed back to program zero point
at end of program. Yes = 1
POSITION LIMIT Turn on position limits.
SOFTWARE LIMITS Turn on software limits.
CRASH DETECT Crash detect
CRASH & IHS USE SAME
INPUT
Used on machines where the torch tip-touch is used to detect both
IHS and Crash signal.
CRASH PAUSE /
TORCHUP
Pause or raise torch on crash
RAISE TORCH ON PAUSE Raise torch when program is paused.
CUTTING LINE Break length
BRIDGE LENGTH Bridge Length
DISPLAY DENSITY Display resolution. Leave set to 0.
SHOW KERF LINE
In Auto Mode, while program is running, draw the running path
showing kerf offset. Yes = 0.
