ESAB Cutting Systems
CROSSBOW Page 69
4.9.2 Auto Mode Menu
ESC AUTO MANUAL EDIT SETUP DIAGNOSE LIBRARY
ESC SKIPTO MANUAL RESUME PREVIEW KERF MORE RETURN
Return to Zero Point
2
nd
Menu Level (More functions)
Adjust Kerf Width
Graphical Preview of loaded program
Resume a Parked Program
Switch to Manual Mode (Jog)
Skip to any pierce point in the program for starting
Return to Main Menu
2
nd
Menu Level (More functions)
ESC OUTLINE WENTAI ROTATE MIRROR SCALE NEST TABBING
Un-Cut Tabs
Pattern nest the loaded part
Scale program larger or smaller than original
Mirror in X or Mirror in Y
Program Rotation
Not used (sign mode)
Run torch around extents of program to check fit on plate
Return to Auto Mode Menu, Main Level
To Next Page
