ESAB Cutting Systems
CROSSBOW Page 95
4.19.2 Additional Function Keys and Indicators
The following keys and functions are available in the Manual Mode:
Key Function
【↑】
【↓】
【←】
【→】
Jog
Pressing any of the four direction arrow keys on the panel will cause the torch to move
in that direction at the Manual Jog Speed.
【G】 Continuous Mode (Jog Latch)
Pressing【G】on the panel while in Manual Mode activates Continuous Jog mode,
which will be indicated on screen. In this mode, pressing any of the four direction
arrow keys will start the torch jogging in that direction, and motion will continue even
after the button is released. Motion will continue until the arrow key is pressed again,
or the 【STOP】key is pressed.
Two arrow keys may be pressed (simultaneously or one after the other) to begin
jogging in a diagonal. Pressing another arrow key while moving in both axes will
change the direction, either cancelling that direction or taking over.
