Appendix 1: Programming Code Reference
This chart is provided for quick reference. Refer to section 4.26 for detailed programming instructions.
Code Format Description
G00 G00 Rapid Motion (Linear)
G01
G01 Xn Yn (Fn)
Linear Motion, with Optional Feed Rate Parameter
G02
G02 Xn Yn In Jn (Fn)
G02 Xn Yn Rn
Clockwise Circular Motion, with Optional Feed Rate Parameter
G03
G03 Xn Yn In Jn (Fn)
G03 Xn Yn Rn
Counter-Clockwise Circular Motion, with Optional Feed Rate Parameter
G04 G04 Ln Time Delay, with Time Parameter L, n = seconds
G20 G20 Inch Mode
G21 G21 Metric Mode
G22 G22 Ln Start Loop, with Number of Loops Parameter L, n = number of loops
G28 G28 Return Home in Both Axes
G40 G40 Kerf OFF
G41 G41 Kerf ON – Left
G42 G42 Kerf ON – Right
G80 G80 End Loop
G90 G90 Absolute Programming Mode
G91 G91 Increment Programming Mode
G92 G92 (Xn Yn) Set Reference Point
M00 M00 Program STOP
M02 M02 Program END
M07 M07 Process ON (Oxy-Fuel/Plasma CYCLE START)
M08 M08 Process OFF (Cut Oxygen/Plasma OFF)
