ESAB Cutting Systems
CROSSBOW Page 189
Appendix 2: Error List
Error Code
Error
01H Extra or illegal character in program
20H Division overflow
21H Circle (G02,G03) start or finish points wrong
22H Circle (G02,G03) diameter wrong
24H Circle (G02, G03) terms wrong
2AH Extra program line, no torch moving
34H Illegal operation
40H Emergency stop key pressed
41H X axis positive direction limit
42H Y axis negative direction limit
43H Y axis positive direction limit
44H Y axis negative direction limit
45H Software coordinate negative limit
46H Software coordinate positive limit
