ESAB CROSSBOW - Torch Station Parts

ESAB Cutting Systems
CROSSBOW Page 181
6.3.8 Torch Station Parts
Figure 145: Torch Lifter
Item Description Part Number
1 Motorized Torch Lifter 0 004 453 032
2
Oxy-Fuel Torch Adaptor - 30 mm ID 0 004 453 056
Oxy-Fuel Torch Adaptor - 31.75 mm ID (For Oxweld C-69/70 Torch) 0 004 453 057
3 Torch Holder 0 004 453 053
4 Cut Oxygen Solenoid Valve 0 004 453 033
5 Solenoid Connecting Pipe 0 004 453 034
6 Connector Plug, 2-pin 0 004 453 045
1
4
5
3
2
6
