The following programs illustrate the use of common M-Codes and programming techniques. Here is
how it would be programmed:
Incremental Program
1:
G91
Incremental Mode
2:
G21
Inch Mode
3:
G00 X3.5 Y5.25
Rapid Move to P1
4:
G41
Activate Kerf Left
5:
M07
Cutting Process Start
6:
G03 X.75 Y.75 J.75
Lead-In
7:
G03 I-1.5
Cut Circle
8:
G03 X-.75 Y.75 I-.75
Lead-Out
9:
M08
Cutting Process OFF
10:
G40
Kerf Off
11:
G00 X5.25 Y3.5
Rapid Move to P2
12:
G41
Activate Kerf Left
13:
M07
Cutting Process Start
14:
G01 Y-8.75
Lead-In, First Side
15:
G02 X-1.5 Y-1.5 I-1.5
Large Corner Radius
16:
G01 X-6.75
Second Side
17:
G02 X-.50 Y.50 J+.50
Small Corner Radius
18:
G01 Y8.75
Third Side
19:
G01 X9.25
Final Side, Lead Out
20:
M08
Cutting Process OFF
21:
G40
Kerf Off
22:
G28
Rapid Move Back to Zero Point
23:
M02
Program End
