Connect the 14-pin plug into the matching socket at the ESAB Plasma Power Source.
Figure 33: PowerCut Machine Interface Pigtail
Figure 34: ESP-101Machine Interface Socket
Number Description
1 Plasma Power Supply
2 14-pin Plasma Interface Connector
2
1
2
1
