【F↓】 Feed Rate Decrease
Pressing 【F↓】on the panel will slowly decrease the Feed Rate Override
Percentage, and the resulting Cutting Speed. The rate is decreased more slowly
when the program is running, and more quickly when the program is paused. To
make large adjustments to the cut speed, the program should be paused and a new
feed rate entered.
【S↑】 Torch Up
Pressing 【Ｓ↑】while the program is running will raise the motorized torch lifter.
【S↓】 Torch Down
Pressing 【Ｓ↓】while the program is running will lower the motorized torch lifter.
【CUTOXY】 Manual Process Re-Start
Press this key to re-start the cutting process.
【PIERCE】 Auto Process Re-Start
The PIERCE key can be used to start a Pierce Cycle then continue cutting in the
Auto Mode. Motion begins after the appropriate timer runs.
If any of the F-keys 【F↑】,【F↓】, or【F】are used to make a speed adjustment while in Program
Pause Mode, a dialog will appear asking the user to select which speed is to be adjusted:
Figure 61: Selecting Speed To Adjust
Use the Up【↑】and Down【↓】keys to select either the Manual Positioning Speed or the Automatic
Cutting Process Speed for adjustment, then press 【ENTER】 to make the selection.
