RX1330 M3 Upgrade and Maintenance Manual 213
Expansion cards and backup units
Figure 130: Installing the full height riser module
Ê Insert the riser card into the system board slot and press down the green
touch points (see circles).
V CAUTION!
Make sure that the EMC springs make contact correctly (see close-ups).
