106 Upgrade and Maintenance Manual TX1320 M4
6.3.1.2 Removing the dummy cover
Figure 30: Removing the dummy cover
Ê Press in on both release latches (1) and remove the dummy cover (2).
V CAUTION!
Keep the dummy cover for future use. If a PSU is removed and not
immediately replaced by a new one, a dummy cover must be installed in
the bay again to comply with applicable EMC regulations and satisfy
cooling requirements.
6.3.1.3 Installing a hot-plug PSU
Figure 31: Folding up the handle
Ê Push the handle of the PSU halfway upward in the direction of the arrow.
