166 Upgrade and Maintenance Manual TX1320 M4
8.2.1.3 Breakout and recess in the HDD fan module
Figure 74: HDD fan module - breakout and recess
1 Breakout for the Oculink cables
If using a PCIe backplane:
Ê Break out the plastic flap of the HDD fan module by hand (see oval)
so that the color-coded Oculink cables can be run through the
breakout. This part can be disposed.
2 Recess for the SAS cable
