Fujitsu PRIMERGY TX1320 M4 - Minimum Startup Configuration

338 Upgrade and Maintenance Manual TX1320 M4
Appendix A
15.4 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Ê "Shutting down the server" on page 49.
Ê "Disconnecting the power cord" on page 50.
Ê Take the system down to its minimum startup configuration.
Ê "Connecting the power cord" on page 60.
Ê Connect a display to the server.
Field Replaceable Units (FRU)
Component Notes and reference
System board
no TPM, expansion cards, or M.2 SSD
installed
1 CPU with heat sink no fan (disconnect fan cable)
1 memory module installed in DIMM slot 1A
Front panel module
1 PSU
Standard PSU or hot-plug PSU installed in bay
PSU 1
Table 6: Minimum startup configuration - components
Cable Notes and reference
Front panel cable
Power cable
Table 7: Minimum startup configuration - cables
