180 Upgrade and Maintenance Manual TX1320 M4
Expansion cards and backup units
Figure 89: Removing the SFP+ transceiver module
Ê Pull the SFP+ transceiver module out of its socket connector.
Ê Attach the protective cap to the SFP+ transceiver module.
I Place the removed SFP+ transceiver module in an antistatic bag or
other protective environment.
9.4 Expansion cards
9.4.1 Installing expansion cards
9.4.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 67
Ê "Shutting down the server" on page 49
Ê "Disconnecting the power cord" on page 50
Ê "Getting access to the component" on page 51
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver (only for installing the slot bracket)
