TX1320 M4 Upgrade and Maintenance Manual 137
Hard disk drives (HDD) and solid state drives (SSD)
7.3.2.3 Concluding steps
Ê "Reassembling" on page 57
Ê "Connecting the power cord" on page 60
Ê "Switching on the server" on page 63
I To configure the installed HDD, see your controller manual.
7.3.3 Removing 3.5-inch non hot-plug HDDs
7.3.3.1 Preliminary steps
Ê If the HDD to be removed is combined into a RAID array, proceed as follows:
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
RAID level Procedure
RAID 0
V CAUTION!
RAID 0 provides no data redundancy.
In case of an HDD/SSD module is defect, all data
are lost!
RAID 1
RAID 5
Removing an HDD module from a RAID 1 or RAID 5 array will
not result in data loss.
However, the removed drive needs to be replaced
immediately by an HDD module of the same or larger
capacity.
I After replacing the HDD module, RAID rebuild will
be performed as a background process, see
section "Performing a RAID array rebuild" on
page 87.
