TX1320 M4 Upgrade and Maintenance Manual 265
Front panel
13.1.1.4 Concluding steps
Ê "Reassembling" on page 57
Ê "Connecting the power cord" on page 60
Ê "Switching on the server" on page 63
Ê "Verifying system information backup/restore" on page 72
Ê "Using the Chassis ID Prom Tool" on page 91
Ê "Resuming BitLocker functionality" on page 87
13.2 Front USB connector
13.2.1 Installing a front USB connector
13.2.1.1 Preliminary steps
Ê "Shutting down the server" on page 49
Ê "Disconnecting the power cord" on page 50
Ê "Getting access to the component" on page 51
13.2.1.2 Removing the FBU tray
Ê Remove the FBU tray, see section "Removing the FBU tray" on page 199.
Ê If applicable, disconnect the FBU adapter cable from the TFM, see section
"Removing the defective TFM" on page 192.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
