15 Appendix A
15.1 Mechanical overview
15.1.1 Server front
Figure 188: Front side 2.5-inch variant
Pos. Component
1 4x 2.5-inch HDDs/SSDs SAS/SATA/PCIe
2ID card slot
3 4x 2.5-inch HDDs/SSDs SAS/SATA
4ODD
5 Backup drive
6 USB connectors
7 Front panel module
