Fujitsu PRIMERGY TX1320 M4 - Concluding Steps; System Board; Replacing the System Board

304 Upgrade and Maintenance Manual TX1320 M4
System board and components
Ê Install the Dual microSD 64GB Enterprise, see section "Installing the Dual
microSD 64GB Enterprise" on page 296.
14.6.4.3 Concluding steps
Ê "Reassembling" on page 57
Ê "Connecting the power cord" on page 60
Ê "Switching on the server" on page 63
14.7 System board
14.7.1 Replacing the system board
Field Replaceable Unit
(FRU)
Hardware: 50 minutes
Software: 10 minutes
Tools: Replacing the system board:
– Phillips PH2 / (+) No. 2 screw driver
– Magnifying glass for inspecting CPU socket springs
(recommended)
Replacing the TPM:
– Bit screw driver
– flat nose pliers
– TPM bit insert
(
*
)
– thin slotted screw driver (2 x 0.4 mm)
(
*
)
(
*
)
For Japan:
– Dedicated TPM screw driver (CWZ8291A)
– TPM module fixing tool (S26361-F3552-L909)
