Fujitsu PRIMERGY TX1320 M4 - List of Used Cables

3TX1320 M4
List of used cables
Cable Plan
Ref.
Name
Number
Routing
Basic
C1
CBL_FRONTPANEL
T26139-Y4015-V303
Basic Cabling
C2
CBL_USB_360
T26139-Y3999-V507
Basic Cabling
C3
CBL SATA ODD
T26139-Y4028-V306
Cabling_ACC_Drv
C4
CBL_MoBo_DRV_Pw_35
T26139-Y4012-V505
CablingPower35inch_HDD
C5
CBL_MoBo_DRV_Pw_25
T26139-Y4012-V504
Cabling_Pwr_25inch_HDD; Cabling_Pwr_25inch_NVMe
C8
CBL_SAS30_SATA_350
T26139-Y4040-V43
CablingData35inchSATA_HDD;
CablingData35inchSATA_HDD_EP4
CablingData35inchSATA_HDD_EP5
C9
CBL_OOB_HDD_2BP
T26139-Y4015-V608
CablingData4/8x25inchSAS_HDD;
CablingData25inchSATA_HDD;
CablingEP5x0i_NVME_EP4x0i_SASSATA
Cabling2xEP5x0i
C10
CBL_PDB_MoBo_Pw
T26139-Y3952-V511
Basic_PDB_Red_PSU
C11
CBL_PDB_MoBo_Sig
T26139-Y3956-V4
Basic_PDB_Red_PSU
C12
CBL USB3.0AN 110
T26139-Y4039-A11
Cabling_ACC_Drv
Accessible drives
C20
CBL_FBU03_550
T26139-Y4031-V102
CablingData4/8x25inchSAS_HDD;
CablingData35inchSATA_HDD_EP4
C21
CBL_SAS-OCU_RY_180
T26139-Y4050-V25
CablingEP5x0i_NVME_Signal
CablingEP5x0i_NVME_EP4x0i_SASSATA
Cabling2xEP5x0i
C22
CBL_SAS-OCU_BG_180
T26139-Y4050-V26
CablingEP5x0i_NVME_Signal
CablingEP5x0i_NVME_EP4x0i_SASSATA
Cabling2xEP5x0i
C23
CBL_HDD_Signal_220
T26139-Y2361-V103
CablingEP5x0i_NVME_Signal
CablingEP5x0i_NVME_EP4x0i_SASSATA
C24
CBL_TFM_EP540_550
T26139-Y4031-V107
CablingEP5x0i_NVME_Signal
CablingEP5x0i_HDD_Signal
CablingData35inchSATA_HDD_EP5
CablingEP5x0i_NVME_EP4x0i_SASSATA
Cabling2xEP5x0i
C25
CBL_I2C_ROC_330
T26139-Y4018-V8
Dual_Micro_SD_64GB_Enterprise
C26
CBL_SAS_IDTWST_340
T26139-Y4040-V77
CablingEP5x0i_HDD_Signal
CablingData4/8x25inchSAS_HDD;
CablingData25inchSATA_HDD
CablingEP5x0i_NVME_EP4x0i_SASSATA
Cabling2xEP5x0i
C27
CBL_HDD_SIGL_2X450
T26139-Y2361-V105
Cabling2xEP5x0i
