288 Upgrade and Maintenance Manual TX1320 M4
System board and components
14.4.3.3 Concluding steps
Ê "Reassembling" on page 57
Ê "Connecting the power cord" on page 60
Ê "Switching on the server" on page 63
14.5 M.2 SSD
The system board offers two M.2 slots (Key M) with support for 42 mm, 60 mm,
80 mm and 110 mm long M.2 SSDs. With the M.2 SSD an internal SSD is
offered. This SSD can be configured as a boot device or data storage device.
14.5.1 Installing an M.2 SSD
14.5.1.1 Preliminary steps
Ê "Shutting down the server" on page 49
Ê "Disconnecting the power cord" on page 50
Ê "Getting access to the component" on page 51
Ê If applicable, "Removing expansion cards" on page 187.
Ê If applicable, remove the HDD fan module 2.5-inch HDD variant, see section
"Replacing the HDD fan module" on page 164.
Ê If applicable, disconnect the Oculink cables from the PCIe backplane.
Ê If applicable, disconnect the SATA cable of the ODD from the system board.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 15 minutes
Tools: – Phillips PH1 / (+) No. 1 screw driver
– Hexagon screw driver
