TX1320 M4 Upgrade and Maintenance Manual 301
System board and components
14.6.3 Replacing the Dual microSD 64GB Enterprise
14.6.3.1 Preliminary steps
Ê "Locating the defective server" on page 47
Ê "Shutting down the server" on page 49
Ê "Disconnecting the power cord" on page 50
Ê "Getting access to the component" on page 51
14.6.3.2 Replacing the Dual microSD 64GB Enterprise
Ê Remove the defective Dual microSD 64GB Enterprise, see section
"Removing the Dual microSD 64GB Enterprise" on page 299.
Ê Remove both microSD cards from the defective Dual microSD 64GB
Enterprise. Proceed as described in the following:
Figure 184: Removing the microSD card
Ê To eject the microSD card, gently push it in and then let go (1).
Ê Pull the microSD card straight out of its slot (2).
Ê Install both microSD cards on the new Dual microSD 64GB Enterprise.
Proceed as described in the following:
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
