112 Upgrade and Maintenance Manual TX1320 M4
Power supply unit (PSU)
6.3.3.4 Concluding steps
Ê Connect the power cord to the new hot-plug PSU and secure it with a cable
tie, see section "Connecting the power cord" on page 60.
Ê Only when replacing a hot-plug PSU in a non-redundant configuration:
"Switching on the server" on page 63
Ê "Performing a fan test" on page 94
6.3.4 Replacing the power distribution board
6.3.4.1 Preliminary steps
Ê "Locating the defective server" on page 47
Ê "Suspending BitLocker functionality" on page 67
Ê "Shutting down the server" on page 49
Ê "Disconnecting the power cord" on page 50
Ê "Getting access to the component" on page 51
Ê If applicable, remove the ODD, see section "Removing the ODD" on
page 246.
Ê If applicable, remove the RDX drive, see section "Removing the RDX drive"
on page 256.
6.3.4.2 Removing the defective power distribution board
Ê Remove all PSUs, see section "Removing a hot-plug PSU" on page 109.
Field Replaceable Unit
(FRU)
Hardware: 25 minutes
Tools: hexagon head, 5 mm / cross PZ2 (not for Japan)
Phillips PH2 (for Japan)
