Fujitsu PRIMERGY TX1320 M4 - HDD Fan Module 2.5-Inch HDD Variant; Replacing the HDD Fan Module; Preliminary Steps

164 Upgrade and Maintenance Manual TX1320 M4
Fans
8.2 HDD fan module 2.5-inch HDD variant
Figure 72: HDD fan position
8.2.1 Replacing the HDD fan module
8.2.1.1 Preliminary steps
Ê "Locating the defective server" on page 47
Ê "Shutting down the server" on page 49
Ê "Disconnecting the power cord" on page 50
Ê "Getting access to the component" on page 51
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
HDD fan 1
HDD fan 2
