158 Upgrade and Maintenance Manual TX1320 M4
Hard disk drives (HDD) and solid state drives (SSD)
Ê Run the OOB cable as shown.
I For the cable plan, see chapter "Appendix B" on page 341.
7.4.7.5 Concluding steps
Ê Insert all HDD/SSD modules, see section "Installing 2.5-inch HDD/SSD
modules" on page 144.
I Ensure that you install the HDD/SSD module in the bay it was located
before the HDD backplane replacement.
Ê "Installing the HDD fan module" on page 167
Ê "Reassembling" on page 57
Ê "Connecting the power cord" on page 60
Ê "Switching on the server" on page 63
7.4.8 Upgrading configuration from up to four up to
eight 2.5-inch HDDs/SSDs
V CAUTION!
All data on all HDDs/SSDs in the array will be lost when deleting the
RAID array! Be sure to back up your data before deleting a RAID array.
For more information, see the "ServerView Suite RAID Management"
user guide.
I After installing or removing an additional backplane, never forget to
change the system information using the Chassis ID Prom Tool.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
