56 Upgrade and Maintenance Manual TX1320 M4
Basic hardware procedures
4.4.3 Removing the HDD bay cover
Figure 9: Removing the HDD bay cover
Ê Turn the key counterclockwise (1) to unlock the accessible drive bay cover
and remove the key.
Ê Open the HDD bay cover in the direction of the arrow and remove it (2).
