278 Upgrade and Maintenance Manual TX1320 M4
System board and components
Ê Enable TPM in the system board BIOS. Proceed as follows:
Ê Switch on or restart your server.
Ê As soon as the startup screen appears, enter the BIOS setup menu.
Ê Select the Advanced menu.
Ê Select the Trusted Computing submenu.
Ê Set the TPM Support and TPM State settings to Enabled.
Ê Under Pending TPM operation, select the desired TPM operation
mode.
Ê Save your changes and exit the BIOS.
I For more information on how to access the BIOS and modify settings,
see the corresponding BIOS Setup Utility reference manual.
14.3.2 Removing the TPM
V CAUTION!
Advise your contact persons that they must provide you with all recovery
keys which belong to the system to restore them in the TPM later.
Field Replaceable Unit
(FRU)
Hardware: 30 minutes
Tools: Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver
Removing the TPM:
– Bit screw driver
– flat nose pliers
– TPM bit insert
(
*
)
(
*
)
For Japan:
– TPM module fixing tool (S26361-F3552-L909)
