Fujitsu PRIMERGY TX1320 M4 Upgrade And Maintenance Manual

Upgrade and Maintenance Manual TX1320 M4
Contents
9.5.2 Removing an FBU . . . . . . . . . . . . . . . . . . . . . . . 202
9.5.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 202
9.5.2.2 Removing the FBU from the tray . . . . . . . . . . . . . . 202
9.5.2.3 Disconnecting the FBU cable from the FBU . . . . . . . . 203
9.5.2.4 Installing the FBU tray . . . . . . . . . . . . . . . . . . . . 204
9.5.2.5 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 204
9.5.3 Replacing an FBU . . . . . . . . . . . . . . . . . . . . . . . 205
9.5.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 205
9.5.3.2 Removing the defective FBU . . . . . . . . . . . . . . . . 205
9.5.3.3 Installing the new FBU . . . . . . . . . . . . . . . . . . . 205
9.5.3.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 206
10 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . 207
10.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 208
10.1.1 Memory sequence . . . . . . . . . . . . . . . . . . . . . . . 208
10.1.1.1 Population rules . . . . . . . . . . . . . . . . . . . . . . . 208
10.1.1.2 Modes of operation . . . . . . . . . . . . . . . . . . . . . 209
10.2 Installing a memory module . . . . . . . . . . . . . . . . . 210
10.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 210
10.2.2 Selecting the memory slot . . . . . . . . . . . . . . . . . . . 210
10.2.3 Installing a memory module . . . . . . . . . . . . . . . . . . . 211
10.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 212
10.3 Removing a memory module . . . . . . . . . . . . . . . . . 213
10.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 213
10.3.2 Removing a memory module . . . . . . . . . . . . . . . . . . 213
10.3.3 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 214
10.4 Replacing memory modules . . . . . . . . . . . . . . . . . 214
10.4.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 214
10.4.2 Removing the defective memory module . . . . . . . . . . . . 214
10.4.3 Installing the new memory module . . . . . . . . . . . . . . . 215
10.4.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 215
11 Processor (CPU) . . . . . . . . . . . . . . . . . . . . . . . . 217
11.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 217
11.2 Upgrading or replacing the CPU . . . . . . . . . . . . . . . 218
11.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 218
11.2.2 Removing the heat sink variant 1 . . . . . . . . . . . . . . . . 219

Fujitsu PRIMERGY TX1320 M4 Specifications

General

Bus type	DMI3
Tjunction	100 °C
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E-2124
System bus rate	8 GT/s
Processor socket	LGA 1151 (Socket H4)
Processor codename	Coffee Lake
Execute Disable Bit	Yes
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor boost frequency	4.3 GHz
Processor operating modes	64-bit
Embedded options available	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	71 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s
Maximum internal memory supported by processor	128 GB
Chassis type	Tower
Product color	Black
HDD size	2.5 \
HDD interface	Serial ATA III, Serial Attached SCSI (SAS)
Optical drive type	DVD±RW
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Server 2012 R2 Foundation Microsoft Windows Storage Server 2012 R2 Standard Microsoft Hyper-V Server 2012 Microsoft Windows Server 2012 Datacenter Microsoft Windows Server 2012 Standard Microsoft Windows Server 2012 Essentials Microsoft Windows Server 2012 Foundation VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Univention Corporate Server 4
Internal memory	16 GB
Maximum internal memory	64 GB
LAN controller	Intel i210
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Power supply	450 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
PCI Express slots version	3.0
PCI Express x4 (Gen 3.x) slots	2
On-board graphics card model	Not available
Processor ARK ID	134856
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	399 mm
Width	98 mm
Height	340 mm
