Fujitsu PRIMERGY TX1320 M4 Upgrade And Maintenance Manual

Upgrade and Maintenance Manual TX1320 M4
Contents
12.3 Backup drive (RDX) . . . . . . . . . . . . . . . . . . . . . . 251
12.3.1 Installing the RDX drive . . . . . . . . . . . . . . . . . . . . . 251
12.3.1.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 251
12.3.1.2 Removing the drive filler cover . . . . . . . . . . . . . . . 251
12.3.1.3 Installing the RDX drive . . . . . . . . . . . . . . . . . . . 253
12.3.1.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 255
12.3.2 Removing the RDX drive . . . . . . . . . . . . . . . . . . . . 256
12.3.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 256
12.3.2.2 Removing the RDX drive . . . . . . . . . . . . . . . . . . 256
12.3.2.3 Inserting the drive filler . . . . . . . . . . . . . . . . . . . 258
12.3.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 258
12.3.3 Replacing the RDX drive . . . . . . . . . . . . . . . . . . . . 259
12.3.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 259
12.3.3.2 Removing the defective RDX drive . . . . . . . . . . . . . 259
12.3.3.3 Installing the new RDX drive . . . . . . . . . . . . . . . . 259
12.3.3.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 259
13 Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 261
13.1 Front panel module . . . . . . . . . . . . . . . . . . . . . . 262
13.1.1 Replacing the front panel module . . . . . . . . . . . . . . . . 262
13.1.1.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 263
13.1.1.2 Removing the front panel module . . . . . . . . . . . . . . 263
13.1.1.3 Installing the front panel module . . . . . . . . . . . . . . 264
13.1.1.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 265
13.2 Front USB connector . . . . . . . . . . . . . . . . . . . . . 265
13.2.1 Installing a front USB connector . . . . . . . . . . . . . . . . 265
13.2.1.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 265
13.2.1.2 Removing the FBU tray . . . . . . . . . . . . . . . . . . . 265
13.2.1.3 Installing the front USB connector . . . . . . . . . . . . . . 266
13.2.1.4 Connecting the front USB connector . . . . . . . . . . . . 267
13.2.1.5 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 267
13.2.2 Removing a Front USB connector . . . . . . . . . . . . . . . 268
13.2.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . 268
13.2.2.2 Disconnecting the front USB connector . . . . . . . . . . . 268
13.2.2.3 Removing the front USB connector from FBU tray . . . . . 269
13.2.2.4 Installing the FBU tray . . . . . . . . . . . . . . . . . . . . 269
13.2.2.5 Concluding steps . . . . . . . . . . . . . . . . . . . . . . 269

Fujitsu PRIMERGY TX1320 M4 Specifications

General

Bus type	DMI3
Tjunction	100 °C
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E-2124
System bus rate	8 GT/s
Processor socket	LGA 1151 (Socket H4)
Processor codename	Coffee Lake
Execute Disable Bit	Yes
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor boost frequency	4.3 GHz
Processor operating modes	64-bit
Embedded options available	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	71 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory bandwidth supported by processor (max)	41.6 GB/s
Maximum internal memory supported by processor	128 GB
Chassis type	Tower
Product color	Black
HDD size	2.5 \
HDD interface	Serial ATA III, Serial Attached SCSI (SAS)
Optical drive type	DVD±RW
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Compatible operating systems	Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Server 2012 R2 Foundation Microsoft Windows Storage Server 2012 R2 Standard Microsoft Hyper-V Server 2012 Microsoft Windows Server 2012 Datacenter Microsoft Windows Server 2012 Standard Microsoft Windows Server 2012 Essentials Microsoft Windows Server 2012 Foundation VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Univention Corporate Server 4
Internal memory	16 GB
Maximum internal memory	64 GB
LAN controller	Intel i210
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Power supply	450 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 85 %
PCI Express slots version	3.0
PCI Express x4 (Gen 3.x) slots	2
On-board graphics card model	Not available
Processor ARK ID	134856
Intel Secure Key Technology version	1.00

Weight and Dimensions

Depth	399 mm
Width	98 mm
Height	340 mm
