322 Upgrade and Maintenance Manual TX1320 M4
The LEDs have the following meaning:
Indicator Status Description
A - Identification blue on The server has been highlighted using
ServerView Operations Manager, iRMC
web interface or the ID button on the front
panel for easy identification.
blue flashing The server has been highlighted for easy
identification using the iRMC (AVR) with
disabled local VGA output.
B - CSS
(Customer Self
Service)
off No critical event detected (CSS
component).
orange on Prefailure event detected (CSS
component).
orange flashing CSS component failure detected.
C - GEL
(Global Error
LED)
off No critical event detected (non CSS
component).
orange on Prefailure event detected (non CSS
component).
orange flashing Non CSS component failure detected.
Possible causes:
– System is out of the specified
temperature range
– Defective sensor
–CPU error
– Error detected by server management
software
F - Controller off Controller okay
orange on Controller failure (PCI card installed on
riser card)
G - Memory off memory module running
orange on memory module failure
H - iRMC off iRMC S5 inactive
green flashing iRMC S5 okay
