Preliminary steps
▶
"Locating the defective server" on page 47
.
▶
"Shutting down the server" on page 49.
▶
"Disconnecting the power cord" on page 50.
▶
"Getting access to the component" on page 51.
▶
Release all HDD modules and pull them out a few centimeters, see
"Removing a 3.5-inch HDD module" on page 180.
CAUTION
The HDD modules need not to be removed.
▶
If you want to remove them nevertheless, check if all HDD
modules are uniquely identified so that you can reinsert them
into their original bays.
▶
Release all dummy modules and pull them out a few centimeters, see
"Removing a 3.5-inch HDD dummy module" on page
178.
▶
"Removing the system air duct" on page
67.
▶
Remove the fan bridge, see "Handling the fan bridge" on page 92.
▶
Disconnect all cables from the defective SAS backplane.
Removing the 3.5-inch HDD bay top cover
The 3.5-inch HDD front cover does not need to be removed in order to
replace a 3.5-inch HDD backplane. In the figures, the front cover has
been removed for illustration purposes only.
Hard disk drive (HDD) / solid state disk (SSD)
184 Upgrade and Maintenance Manual TX2550 M5
