Connect the following cables to the HDD backplane 1 in the following
sequence:
1 SAS cable from connector "MLC1" on SAS controller to connector
"X9"
2 Power cable from connector "PWR1" on system board to connector
"X40"
If applicable, to an additional accessible drive to connector "X17" or
connector "X18"
If applicable, connect the OOB cable, see "Replacing the OOB cable"
on page 554
.
For the cable plan, see "Appendix B" on page 589
.
Concluding steps
▶
Install the fan bridge, see "Handling the fan bridge" on page 92
.
▶
"Installing the system air duct" on page 68.
▶
Insert all HDD modules, see "Installing a 3.5-inch HDD module" on
page 178.
Make sure that you reinstall the HDD module in the bay it was located
before the HDD backplane replacement.
▶
Insert all dummy modules, see "Installing a 3.5-inch dummy module" on
page 181.
▶
"Reassembling" on page
68
.
▶
"Connecting the power cord" on page 82.
▶
"Switching on the server" on page 83.
Hard disk drive (HDD) / solid state disk (SSD)
194 Upgrade and Maintenance Manual TX2550 M5
