Figure 233: Removing the expansion card
▶
Fold up the green locking handle on the slot cover clamp.
▶
Remove the slot cover clamp.
▶
Carefully remove the expansion card from its slot.
Installing the slot cover
CAUTION
▶
If the expansion card is removed and not replaced with a new one,
the slot cover must be reinstalled due to cooling, to comply with
applicable EMC regulations and to protect against fire.
Expansion cards and backup units
TX2550 M5 Upgrade and Maintenance Manual 359
