GE Mark VIeS - Page 185

STCI Screw STCI Name Channel SUAA Screw SUAA Name Use
44
Input 22 (Signal)
22 SUAA #2 screw 16 I/O+ for Channel 22
Return path from switch #22
45
Input 23 (Positive)
23 SUAA #2 screw 19
PWR_RET for Channel 23
Positive feed to switch # 23
46
Input 23 (Signal)
23 SUAA #2 screw 21 I/O+ for Channel 23
Return path from switch #23
47
Input 24 (Positive)
24 SUAA #2 screw 20
PWR_RET for Channel 24
Positive feed to switch # 24
48
Input 24 (Signal)
24 SUAA #2 screw 22 I/O+ for Channel 24
Return path from switch #24
49 Excitation Positive ALL None None
Leave disconnected,
internally supplied by YUAA
50 Excitation Positive ALL None None
Leave disconnected,
internally supplied by YUAA
51
Excitation Negative
ALL None None
Leave disconnected,
internally supplied by YUAA
52
Excitation Negative
ALL None None
Leave disconnected,
internally supplied by YUAA
YUAA Universal I/O Modules GEH-6855_Vol_II System Guide 185
Public Information
