Note Sensors monitoring dynamic pressure typically measure RMS.
If OperatingMode is Legacy, this value is ignored and legacy Peak algorithm is used.
FilterType – Select Wideband Filter type for Dynamic Pressure data. Selections are None, Lowpass, Highpass, Bandpass.
Filtrhpcutoff, Filtrlpcutoff – Cutoff (-3dB) point for high-pass and low-pass filters, respectively.
Fltrhpattn, Fltrlpattn – Attenuation for high-pass and low-pass filters, expressed as number of poles to use in Butterworth
filters. Selections are 2-pole, 4-pole, 6-pole, 8-pole, and 10-pole.
TMR_DiffLimt – TMR Voter Disagreement Detection Diagnostic alarm threshold for VIBn value. Value is expressed as
absolute difference in EU.
SysLimit#, SysLim#Enabl, SysLim#Latch, SysLim#Type – Refer to System Limits feature.
LMVibnA, LMVibnB, LMVibnC:
TMR_DiffLimt – TMR Voter Disagreement Detection Diagnostic alarm threshold for LMVibnA/B/C value. Value is
expressed as absolute difference in EU. SysLimit#, SysLim#Enabl, SysLim#Latch, SysLim#Type – Refer to System Limits
feature.
YVIB Vibration Monitor Modules GEH-6855_Vol_II System Guide 259
Public Information
