10.9.3 Operation
All 24 connectors on the Euro block are connected to ground through the two grounding screws at the ends of JGND. These
make contact with the metal mounting bracket, which is connected to ground. If nylon washers are used to isolate the board,
ground currents must be wired into an alternate system location.
10.9.4 Specifications
Item
JGND Description
Terminals
24 terminals on Euro type terminal block
Ambient Rating for Enclosure Design -40 to 70ºC (-40 to 158 ºF)
Board Dimensions
3.175 cm high x 12.7 cm wide (1.25 in x 5.0 in)
Mounting
Held with three screws to sheet metal bracket on side of terminal board
PDM Power Distribution Modules GEH-6855_Vol_II System Guide 397
Public Information
