8.5 Converting Input Values (Scaling Function)
133
8
Chapter 8 Utility Functions
1. For scaling, set the [Method] to [Ratio].
2. Point the cursor to the conversion rate setting. Select [dB Scaling] in the
function column.
3. In the displayed entry field and physical quantity field, enter 40 dB and 60 dB,
respectively.
After entering the values, select [Confirm].
See: "8.1.3 Alphanumeric Input" ( p.121)
The conversion rate for the entered dB value is entered. (The offset becomes 0.)
Using the dB value
Example 5
Acquiring the conversion rate to convert 40 dB input to 60 dB
