Chapter 10
Numerical Calculation Functions_____________ 173
10.1 Numerical Calculation Workflow .....................................174
10.2 Settings for Numerical Value Calculation ........................176
10.2.1 Displaying Numerical Calculation Results ............................179
10.3 Judging Calculation Results ............................................180
10.3.1 Display of Judgment Results and Signal Output ..................182
10.4 Saving Numerical Calculation Results ............................183
10.5 Printing Numerical Calculation Results ...........................184
10.6 Numerical Calculation Type and Description ..................185
Chapter 11
Waveform Calculation Functions_____________ 189
11.1 Waveform Calculation Workflow .....................................190
11.2 Settings for Waveform Calculation ..................................192
11.2.1 Displaying the waveform calculation results .........................193
11.2.2 Setting constants ..................................................................195
11.2.3 Changing the display method for calculated waveforms ......196
11.3 Waveform Calculation Operators and Results ................198
Chapter 12
Memory Division Function __________________ 201
12.1 Recording Settings ..........................................................203
12.2 Display Settings ..............................................................204
Chapter 13
FFT Function _____________________________ 207
13.1 Overview and Features ...................................................207
13.2 Operation Workflow ........................................................208
13.3 Setting FFT Analysis Conditions .....................................209
13.3.1 Selecting the FFT Function ..................................................209
13.3.2 Selecting the Data Source for Analysis ................................210
13.3.3 Setting the Frequency Range and
Number of Analysis Points ...................................................211
13.3.4 Thinning Out and Calculating Data .......................................213
13.3.5 Setting the Window Function ................................................214
13.3.6 Setting Peak Values of Analysis Results ..............................215
13.3.7 Averaging Waveforms ..........................................................216
