5.2 Saving Data
71
5
Chapter 5 Saving/Loading Data & Managing Files
7
Select the channel to save.
Move the cursor to the [Save Channel]
item.
Select
8
Set whether to create folders.
Move the cursor to the [Folder to save] item.
Select
9
Set the save method for when the storage media runs out of
space.
Move the cursor to the [Save method] item.
Select
10
Confirm the measurement configuration and other settings,
then start measurement (START key).
After the data is acquired, the screen image is saved automatically to the specified
storage media.
Disp Ch Saves the channels of all sheets for which waveform display is set
to [On]. (default setting)
All Ch
Saves all measured channels (in the case of the memory function,
channels has been set as [Used Ch] on the Status settings
screen).
No A folder is not created when measurement starts.
Yes
A folder is created automatically when measurement starts and
files are saved in the folder.
Normal
Save
Automatic saving stops when the storage media becomes full.
Delete
Save
Old files are deleted and automatic saving is performed when the
storage media becomes full. (Waveform files only.)
The [Folder to save] setting is set automatically to [Yes].
7
8
9
Maximum number of files per folder
The combined maximum for files and folders created in one folder is 5,000.
See: "Auto Save Operations" ( p.72)
To clear the Auto Save dialog box
Press the SAVE key to turn the dialog box display on and off.
