3. Remove the spring that holds the cap from below.
4. Attach the spring to the new service station cap and place it in position.
Finish oîž« after replacing a service station cap
1. Put back the cover and screw it into place.
2. Turn on the printer in the correct way for maintenance operations: see Turn the printer on on page 160.
Replace an intermediate tank
Risk of burns Risk of trapped îžngers Hazardous moving part
For more safety information, see Safety precautions on page 2
You will need to replace an intermediate tank if the bag breaks.
Pr
epare to replace an intermediate tank
1. Ensure that you have the Intermediate Tank Kit (CZ056-67073), which is included in the Standard
Uptime Kit (D4J02A).
2. Ensure that the printer is not printing.
3. Turn oîž« the printer in the correct way for maintenance operations: see
Turn the printer oîž« on page 160.
Replace an intermediate tank
1. Unscr
ew the pointed screws and remove the cover to access the intermediate tanks.
258 Chapter 8 Hardware maintenance ENWW
