HP Latex 3000 Series

Load a roll into the printer
The objective when loading substrate is to get a uniform tension across its width and length to minimize the
risk of skew, wrinkles, and telescoping. There are four ways in which the substrate can pass through the
printer:
●
Roll-to-roll conguration
●
Dual r
oll-to-roll conguration
●
R
oll-to-free-fall conguration
●
R
oll-to-collector conguration
For each
conguration, there are two ways of loading the substrate:
ENWW Load a roll into the printer 53
