12. Tighten the screws.
13. Inser
t the new foam.
14. Slide in the c
over.
15. Close the service position window.
Finish oîž« replacing the oiler foams
1. Ensure that all windows, covers, and doors are closed and remain in their original position.
2. Turn on the printer in the correct way for maintenance operations: see
Turn the printer on on page 160.
Empty the oil collector caps
Risk of burns Crush hazard Risk of trapped îžngers Hazardous moving
p
art
Light radiation hazard Electric shock hazard
For more safety information, see
Safety precautions on page 2
190 Chapter 8 Hardware maintenance ENWW
