8. Reinsert both îžlters. There is only one way to insert them that works. If you feel resistance, try to insert
the îžlter the other way round.
9. Cl
ose the lids.
10. Close the latches.
11. Close the service position window.
Clean and grease the service station transmission and rods
Risk of burns Crush hazard Risk of trapped
îžngers Hazardous moving
part
Light radiation hazard Electric shock hazard
For more safety information, see
Safety precautions on page 2
NOTE: U
se gloves when applying grease to the gears.
Clean and grease the service station transmission
1. Ensur
e you have the machine grease and oil kit, included in the Printer Maintenance kit.
2. Move the carriage beam to its highest position (it takes around 2 minutes).
3. Move the carriage to service position.
ENWW Clean and grease the service station transmission and rods 277
