3. Tilt the printhead a little before taking it completely out of its pocket.
4. If the prin
thead is to be reused, protect it using its orange sealing cap.
CAUTION: Make sure each printhead uses its own cap and not the cap for some other printhead. This is
especially important with the optimizer printhead caps as there is a high risk of nozzle damage if they
are mixed with the color printheads and vice versa. The optimizer caps are labeled as shown below.
NOTE: R
emember which printhead came from which slot; the printer will report an error if you later replace
a printhead in a dierent slot.
Insert a printhead
1. Check th
at the new printhead is of the correct colors.
NOTE: Each printhead has a unique shape and cannot be inserted into the wrong slot. Do not try to
force it.
2. Sh
ake the printhead according to the instructions on the packaging.
ENWW How to work with ink system components 119
