3. Load the split spindles in the printer.
4. Mo
ve the rolls to the center of the printer. Accurately position each roll following one of the spindle
marks. The input and output rolls should be positioned identically on their respective parts of the
spindle.
5. Inate
the valves at both ends by connecting the air gun to the pneumatic connectors.
Latex 3500 dual-roll split spindles specications
Minimum roll width 635 mm (25 in)
Maximum roll width 2 × 1.55 m (2 × 61 in)
Minimum gap between rolls 134 mm (5.3 in)
Maximum roll diameter 400 mm (15.75 in)
Maximum total weight of both rolls 2 × 200 kg (2 × 440 lb)
52 Chapter 3 Handle the substrate ENWW
