7. Unwind a length of substrate.
If your printer is an HP Latex 3500, you have to load the paper making sure it is loaded behind the
diverter.
8. P
lace it in the print zone.
9. Push the subs
trate through the printer until it reaches the output spindle.
10. Align the substrate by checking that the substrate edge is in the same position on the input and output
spindles. This can be done by using the rulers on the spindles or by measuring the distance between the
right edge and the side plate.
11. When the substrate is evenly tensioned and at (no wrinkles or bumps), attach it to the empty core with
adhesive tape. Tape it îžrst in the center, and then at the left and right sides, making sure not to pull the
substrate excessively or leave it wrinkled.
12. If y
ou are using them, place the substrate edge holders into position and attach them at the front.
13. Close the front door and the curing module.
ENWW Load a roll into the printer 63
